Product Details
C3-series
IP-based Door Access Control Panel
Choice of Readers
- Supports a full range of card readers.
- Compatible with stylish and waterproof ZK KR-Series readers.
- C3 supports any Wiegand-output reader, including HID Prox, iClass, and XceedID Multi-Technology.
Communication
- Easily integrates into your network.
- Supports both TCP/IP and RS-485 communication protocols.
- Includes an auto-discovery tool for quick and easy configuration of network parameters.
Lowest Total Cost of Ownership
- Cost-effective solution.
- C3 controller firmware can be upgraded without advanced tools.
- Firmware updates provide new features, enhancing the system’s value over time.
Capacity
- Supports up to 30,000 badge users.
- Stores up to 100,000 events and transactions.
- Data remains preserved during power outages.
- Operates seamlessly even if the network connection is lost.
More Than Door Control
- Offers additional control and interface capabilities.
- Auxiliary relays can control lights, alarms, and intrusion detection systems.
- Supports extra locking devices or gate controllers.
Built-In Advanced Access Control
- Includes advanced features like Anti-Passback, First-Card Opening, Multi-Card Opening, Duress Password Entry, and Auxiliary Input/Output linkages.
For Software Developers
- Free SDK available for integration with third-party security or personnel management systems.
- ZK can customize C3 firmware to meet specific customer requirements upon request.
